How-to: Debug a running app with rk-devtools

This walkthrough takes you end to end with the DevTools CLI: build the tool, point a running app at it, reproduce a bug, and pin down the exact action and state change that caused it — all from the terminal, no browser extension, no IDE debugger.

The CLI is headless and scriptable, which makes it the right tool for:

  • debugging on devices/targets without a browser DevTools extension (iOS, Desktop, Wasm, CI),
  • capturing a reproducible .jsonl trace to attach to a bug report,
  • letting an AI agent or script answer "what fired before the crash?" — see the agent walkthrough.

:::caution Experimental The DevTools modules are experimental and the CLI is an unpublished developer tool — you build it from the repo, it is not a Maven artifact. :::

Screenshots in this guide are placeholders. Image slots reference the labelled placeholder PNGs in ./img/devtools-cli/; replace them with real captures against the TaskFlow sample when filling this page in.

The scenario​

We use the TaskFlow Kanban sample. TaskFlow does optimistic card moves against a fake backend: a move applies immediately, then the server result either confirms it (CardOpSucceeded) or rejects it and rolls back (CardOpFailed). To make rejections happen on demand, open Settings and set the failure-rate slider to 100%. Now every move you make snaps back. We'll use the CLI to watch that optimistic-apply → reject → rollback trace and confirm the in-flight bookkeeping behaves.

TaskFlow board after a rejected, rolled-back card move

Step 1 — Build the CLI​

rk-devtools installs from the repo with Gradle's installDist:

./gradlew :redux-kotlin-devtools-cli:installDist

# resulting launcher:
redux-kotlin-devtools-cli/build/install/rk-devtools/bin/rk-devtools

Put it on your PATH for the session so the rest of the commands read cleanly:

export PATH="$PWD/redux-kotlin-devtools-cli/build/install/rk-devtools/bin:$PATH"
rk-devtools --help
Usage: rk-devtools [<options>] <command> [<args>]...

Options:
  -h, --help  Show this message and exit

Commands:
  serve
  stores
  actions
  diff
  state
  tail

Run rk-devtools <command> --help for a command's flags (e.g. rk-devtools actions --help).

rk-devtools --help in a terminal

Step 2 — Start the receiver​

serve hosts the bridge receiver on 127.0.0.1:9090 and writes one <storeKey>.jsonl capture per store under .rk-devtools/. Leave it running in its own terminal before you launch the app:

rk-devtools serve
rk-devtools: listening on 127.0.0.1:9090
rk-devtools: writing captures to ./.rk-devtools/
rk-devtools: waiting for app… (Ctrl-C to stop)

Useful flags: --port, --host, --out <dir>, --token <t> (required for non-loopback binds), and --ui to also launch the desktop GUI monitor against the same ingest.

serve waiting for a connection

Step 3 — Point the app at the bridge​

TaskFlow already does this — AppStore.kt / AccountStore.kt wire the devTools(...) enhancer and attach a BridgeOutput(BridgeConfig(clientId = "taskflow")) to the hub, pointing at 127.0.0.1:9090. So you can skip straight to launching the app.

For your own app, add a BridgeOutput to the DevTools hub in debug-only code (the store must already carry the devTools(...) enhancer — see Wiring the store):

import org.reduxkotlin.devtools.DevToolsHub
import org.reduxkotlin.devtools.bridge.BridgeConfig
import org.reduxkotlin.devtools.bridge.BridgeOutput

DevToolsHub.registerOutput(
    BridgeOutput(
        BridgeConfig(
            host = "127.0.0.1",
            port = 9090,
            startEnabled = true,
            clientLabel = "my-app",
        ),
    ),
)

Launch the app; serve prints the connection (TaskFlow streams two stores — its per-account board store and the root store):

rk-devtools: client connected — TaskFlow
rk-devtools: capturing store taskflow::TaskFlow
rk-devtools: capturing store taskflow::TaskFlow-root

Step 4 — List the captured stores​

Move a card in the app (with failure-rate at 100% it'll snap back), then confirm the CLI is recording:

rk-devtools stores
taskflow::TaskFlow      TaskFlow
taskflow::TaskFlow-root TaskFlow-root

(Each row is <storeKey> then the store's display name.)

The clientId::storeInstanceId key is what you pass to --store when more than one store is captured (here clientId = "taskflow" and the instance id is each store's DevToolsConfig name — TaskFlow for the board store, TaskFlow-root for the root store). The board/card actions live in taskflow::TaskFlow. With a single store, the query commands resolve it automatically.

stores listing two captured stores

Step 5 — Scan the recent action log​

rk-devtools actions --store taskflow::TaskFlow --last 5

Output is one JSON object per line (pipe it to jq); ts is epoch millis:

{"actionId":1,"type":"AddCard","store":"taskflow::TaskFlow","ts":1718450691120}
{"actionId":2,"type":"CardMoveRequested","store":"taskflow::TaskFlow","ts":1718450691402}
{"actionId":3,"type":"CardOpFailed","store":"taskflow::TaskFlow","ts":1718450692118}
{"actionId":4,"type":"CardMoveRequested","store":"taskflow::TaskFlow","ts":1718450692980}
{"actionId":5,"type":"CardOpFailed","store":"taskflow::TaskFlow","ts":1718450693640}

There's the pair we want: an optimistic CardMoveRequested at 2 and its rejection CardOpFailed at 3. Filter to just the card traffic with a type glob:

rk-devtools actions --store taskflow::TaskFlow --type '*Card*' --last 5

filtered action log showing CardOpFailed

Step 6 — Diff the offending action​

diff shows the per-field JSON change each action produced. TaskFlow's state is a ModelState, so the diff is keyed by model class. Look at what the rejection did:

rk-devtools diff --store taskflow::TaskFlow --since 3 --until 3 --pretty

The diff tier adds a diff array of {op, path, before, after} entries (--pretty expands it; drop it for one object per line):

{
    "actionId": 3,
    "type": "CardOpFailed",
    "store": "taskflow::TaskFlow",
    "ts": 1718450692118,
    "diff": [
        { "op": "CHANGED", "path": "SyncModel.inFlight", "before": ["card-7"], "after": [] },
        { "op": "ADDED", "path": "SyncModel.lastError", "before": null, "after": "card-7 rejected by backend" },
        { "op": "CHANGED", "path": "BoardModel.board.card-7-column", "before": "done", "after": "doing" }
    ]
}

The trace confirms the rollback is correct: card-7 leaves SyncModel.inFlight the moment the op resolves, lastError records why, and BoardModel reverts the optimistic move via the action's inverse op. (Exact serialization depends on the serializer tier — JVM renders structured JSON; other targets may render toString().)

diff output showing the rejection rollback

Step 7 — Confirm against full state​

Print the full state snapshot at that action to confirm the post-rollback shape:

rk-devtools state --store taskflow::TaskFlow --at 3 --pretty

state prints the whole serialized state at that action (a ModelState, keyed by model class):

{
    "SyncModel": {
        "online": true,
        "pendingCount": 0,
        "inFlight": [],
        "lastError": "card-7 rejected by backend"
    },
    "BoardModel": {
        "board": { "name": "Launch", "card-7-column": "doing" }
    }
}

inFlight is empty and card-7 is back in its original column — the optimistic move was cleanly reverted. If inFlight had retained card-7, that would be the "stuck Saving…" bug to chase; here it's clean.

Watching live: tail --follow​

While iterating, stream actions as they fire instead of re-running actions:

rk-devtools tail --follow

--follow polls the capture every 300ms and prints new actions (same JSON-line format as actions). Combine with --type to watch only what you care about:

rk-devtools tail --follow --type '*Card*'

tail --follow streaming actions

Other scenarios​

GoalCommand
Everything since a known-good actionrk-devtools actions --since 40
A bounded windowrk-devtools actions --since 40 --until 50
Only actions in a time windowrk-devtools actions --since-time 2026-06-15T12:04:00Z
Full state + diff for every actionrk-devtools actions --format full --pretty
One specific store when several are capturedrk-devtools diff --store 'taskflow::TaskFlow' --last 5
Inspect captures with the GUI toork-devtools serve --ui

Captures are just files​

Each store is a plain <storeKey>.jsonl under .rk-devtools/ — commit one to a bug report, diff two runs, or decode it programmatically with the bridge codec (decodeRecording / decodeRecordingLenient). See the bridge module.
